DTOP距离测量模组

所属分类：智能传感

产品卖点：

距离测量模组是一种基于DTOF技术，通过发射一束短脉冲的激光，并测量该光束从发射到被目标物体反射回接收器的时间，从而计算出目标物体与测量设备之间的距离。利用光莆自主研发的SPAD和独特的ToF采集与处理技术，可实现最大4米的精确距离测量，精确到仅2mm误差。适用于智能家居设备如饮水机、咖啡机等的液位检测、机器人导航等

» 产品特征

• 体积小，IP67防水防尘，安装方便

• 激光Vcsel，光学抗干扰能力强

• 符合1类人眼安全标准

• 精准测量液体表面高度

• 感应距离可按需求配置

产品详情

» 规格参数

工作电压	DC 5V（4-18V）
工作电流	22-28 mA
感应距离	10-200mm（±5mm）
照度	400 Lux（可调光）
输出方式	10Hz脉冲式输出
防水等级	IP67
工作环境	-40℃~85℃ , 0%RH~85%RH

» 应用场景
